Product Description
CROSBY WIRE ROPE CLAMP 1/4 IN - New original packaging
Material
Galvanized Steel
For Wire Rope
Diameter
1/4"
Construction
6 × 19 Fiber Core
6 × 19 IWRC
6 × 26 IWRC
6 × 37 IWRC
7 × 19 IWRC
7 × 19 Strand Core
19 × 7 Strand Core
Number of Clamps Required
2
Rope Turnback
4 3/4"
Clamp
Width
1 7/16"
Height
1 3/8"
Thickness
1 1/4"
Color
Red
Fabrication
Forged
Required Torque
15 ft·lbf
Rope Capacity Adjustment Factor
80%
Specifications Met
ASME B30.26, Fed. Spec. FF-C-450
Application
Not for Lifting
Attachment Type
Loop
Fitting Type
Rope Clamp
Required Installation Tool
Torque Wrench
Country of Origin
France
DFARS Compliance
Specialty Metals COTS-Exempt
Export Control Classification Number (ECCN)
EAR99
REACH Compliance
REACH (EC 1907/2006) (06/14/2023, 235 SVHC) Compliant
RoHS Compliance
Not Compliant
Schedule B Number
732690.8695
U.S.–Mexico–Canada Agreement (USMCA) Qualifying
No
These must be oriented with the saddle on the long (live) end and U-bolt on the short (dead) end. Their forged fabrication makes these clamps more reliable in critical applications such as tie downs and support lines. They’re also known as wire rope clips. Clamps have a thick coating for corrosion resistance.
Warning: Test all assemblies for required strength before use. Do not use with coated rope unless the coating is removed.
