Product Description
WEIDMULLER 405856 12V RELAY MODULE DPDT - New no packaging
Storage temperature
-40 °C...85 °C
Ambient temperature
-40 °C…70 °C
Humidity
40 °C / 93 % rel. humidity, no condensation
Environmental Product Compliance
RoHS Compliance Status
Compliant without exemption
REACH SVHC
No SVHC above 0.1 wt%
Rated data UL
Certificate No. (cURus)
E522350
Control side
Rated control voltage
12 V DC
Rated current DC
33.3 mA
Power rating
400 mW
Coil resistance
360 Ω ± 10 %
Status indicator
No
Load side
Rated switching voltage
250 V AC
Continuous current
8 A
Max. switching frequency at rated load
0.1 Hz
Min. switching power
1 mA @ 24 V
10 mA @ 12 V
100 mA @ 5 V
Inrush current
15 A / 4 s
AC switching capacity (resistive), max.
2000 VA
DC switching capacity (resistive), max.
192 W @ 24 V
Switch-on delay
≤ 8 ms
Switch-off delay
≤ 6 ms
Contact type
2 CO contact (AgNi)
Mechanical service life
30 x 106 switching cycles
General data
Test button available
No
Mechanical switch position indicator
No
Colour
Transparent
UL 94 flammability rating
V-2
Insulation coordination
Rated voltage
250 V
Pollution severity
2
Surge voltage category
III
Insulating material group
IIIa
Clearance and creepage distances for control side - load side
≥ 10 mm
Dielectric strength for control side - load side
5 kVeff / 1min
Dielectric strength of neighbouring contacts
2.5 kVeff / 1 Min.
Dielectric strength of open contact
1 kVeff / 1 min
Protection degree
IP20
Further details of approvals / standards
Certificate No. (CSA)
249409-2426937
Certificate No. (VDE)
40020589
Certificate No. (cURus)
E522350
Connection data
Wire connection method
Plug-in connection
Pitch in mm (P)
5 mm
Classifications
ETIM 8.0
EC001437
ETIM 9.0
EC001437
ETIM 10.0
EC001437
ECLASS 14.0
27-37-16-01
ECLASS 15.0
27-37-16-01
