Product Description
GAS SPRING MINIATURE 1.5 STROKE 5.11 EX. 3.61 COMP. 30LB 316SS - New no packaging
Body
Diameter
0.47"
Material
316 Stainless Steel
Rod
Diameter
0.16"
Thread Size
M4
Thread Pitch
0.7 mm
Material
316 Stainless Steel
Extended Length
5.11"
Compressed Length
3.61"
Stroke Length
1.5"
Maximum Cycles per Minute
4 cpm
Maximum Cycles
Not Rated
Lockable
No
Removable End Fittings
Yes
Eyelet
Length
0.63"
ID
0.16"
Thickness
0.16"
Material
316 Stainless Steel
Thread Size
M4
Thread Pitch
0.7 mm
Thread Length
0.22"
Temperature Range
-13° F to 158° F
Extension Force
5 lbf
Compression Force
6 lbf
Force Mechanism
Compressed Nitrogen Gas
Mounting Position
Vertical with Rod Down
Performance
Corrosion Resistant
Refillable
No
Seal Material
Rubber
