Product Description
GEMS SENSORS 164860 LEVEL SWITCH 1/2 MNPT 316SS 22AWG W/POLYP FLOAT TYPE-9 - New original packaging
The LS-7 Series Single-Point Type 11 Level Switches feature durable 316 stainless-steel construction with 316 SS floats, ideal for small tanks or vessels in rugged environments. Fully FDA-compliant, these switches are perfect for food, beverage, and industrial applications requiring reliable, long-lasting point-level sensing.
Product Line
Level Sensors & Switches
Electrical Termination
24" Long, 22 AWG, TPE Zip Cord
Float Diameter Range
0.625 in
Float Material
Polypropylene
Maximum Pressure Rating
100 PSI
Minimum Liquid Specific Gravity
0.55
Model Type
LS-7 Type 9
Mounting Type
1/2" NPT Male
Mounting Orientation
Horizontal
Primary Material Of Construction
Alloy
Sensor Type
Float
Stem & Mounting Material
Stainless Steel
Switch Operation
Normally Open
(Reversible)
Switch Type
SPST (20 VA)
Wetted Material
Polypropylene
316 Stainless Steel
316 Stainless Steel, Polypropylene
Product Family
Single-Point Level Switch
Product Type
Float - Single Point
Maximum Operating Temperature [°F]
225 °F
Minimum Operating Temperature [°F]
-40 °F
