Product Description
OSBORN LOAD RUNNERS PLRS-1 1/4 CONCENTRIC ROLLER PLAIN 1-1/4 IN DIA STAINLESS STEEL 97735 - New no packaging
Item No. 97735
Description PLRS-1-1/4
Detail
Wt Std Pk lbs 1 lbs
Std Pk 1
Type LR Imperial
Brand Osborn
Part Number PLRS-1-1/4
Scale Imperial
A Roller Dia In 1-1/4 In
A Tolerance +0.000 -0.001
B Roller Width In 0.844 In
K Stud Dia In 1/2 In
K Tolerance +0.000 -0.001
L Stud Length In 1-1/4 In
M Thread Length In 5/8 In
N Thread 1/2-20
R Shoulder Dia In 5/8 In
S Shoulder Length In 0.031 In
Recommended Mounting Hole Size In 0.501 In
Recommended Mounting Hole Tolerance +0.001 -0.000
Radial Capacity 3000hrs L10 Life @100 RPM lbs 480 lbs
Radial Capacity 500hrs L10 Life @33-1/3 RPM lbs 1250 lbs
Radial Capacity Static Limit lbs 520 lbs
Thrust Capacity Static Limit lbs 320 lbs
Mounting Member Thickness Max In 3/4 In
Mounting Member Thickness Min In 5/8 In
Stud Capacity Bend @B/2 lbs 350 lbs
Stud Capacity Bend @B lbs 160 lbs
Stud Capacity Shear lbs 1290 lbs
Retaining Ring Capacity lbs 230 lbs
